Electric Forklift SF-FB30
$23,400.00
+1(250) 567-2755
Electric Forklift SF-FB30
Product Overview | Important Attributes | Packaging & Shipping Information | Product Highlights
Product Overview:
3T Electric Forklift by SUNFavor. An innovative design made with Lithium Power battery. Advantages of a lithium battery forklift include, 4000 Full charging cycles with at least 80% residual capacity, Maintenance free, and high safety and reliabilty.
Important Attributes
Model
FB30
Power form
electric
Voltage platform
V
80
Operation form
Seated
Rated load
kg
3000
Rated load center distance
mm
500
Front overhang
mm
450
Rear overhang
mm
415
Wheelbase
mm
1650
Weight (without battery)
kg
4250/4050
Axle load Full load (front/rear)
kg
6570/680
Axle load unladen (front/rear)
kg
1880/370
Tire type
pneumatic tire
Number of wheels (x=drive wheels)
2x/2
Front Tire Size
28*9-15-14PR
Rear Tire Size
6.50-10-10PR
Front wheelbase
mm
1000
Rear wheelbase
mm
570
Mast tilt angle (front/rear)
°
6/12
Height at retraction
mm
2085
Free lift height
mm
130
Maximum lifting height
mm
3000
Maximum height during operation
mm
4025
Height of roof rack
mm
2145
Body length
mm
2685
Body width
mm
1230
Fork size
mm
1070*122*45
Distance between forks outside (min/max)
mm
250-1085
Ground clearance of roof frame (full load)
mm
115
Minimum Ground Clearance of Frame
mm
130
Minimum turning radius
mm
2500
Maximum traveling speed (full load/no load)
km/h
15/16
Max. lifting speed (fully loaded/unloaded)
mm/s
320/360
Lowering speed
mm/s
450/410
Maximum Hook Traction (fully loaded)
N
16500
Climbing capacity (fully loaded/unloaded)
%
20/20
Traveling brake
hydraulic
Parking brake
Mechanical
Nominal power of traction motor
kW
10AC
Nominal power of oil pump motor
kW
16AC
Battery type
Li-ion
Standard Battery Voltage/Capacity
V/Ah
76.8/200
Standard Battery Weight
kg
200
Hydraulic system working pressure
MPa
18.5
Packaging & Shipping Information
Packaging Details
Forklift Nude Packing.
Sales Unit
Single item
Rated load
3000KG
Product Highlights
★
Integrated Battery Management System (BMS)
★
Standard lithium battery
★
Standard fork
