Electric Forklift SF20 PRO
$33,000.00
+1(250) 567-2755
Electric Forklift SF-FB20 PRO
Product Overview | Important Attributes | Packaging & Shipping Information | Product Highlights
Product Overview:
2T Electric Forklift by SUNFavor. An innovative design made with Lithium Power battery. Advantages of a lithium battery forklift include, 4000 Full charging cycles with at least 80% residual capacity, Maintenance free, and high safety and reliabilty.
Important Attributes
Model
SF20 PRO
Power form
electric
Voltage platform
V
80
Operation form
Seated
Rated load
kg
2000
Rated load center distance
mm
500
Front overhang
mm
370
Wheelbase
mm
1410
Weight (without battery)
kg
3150/2960
Axle load Full load (front/rear)
kg
4650/540
Axle load unladen (front/rear)
kg
1250/190
Tire type
pneumatic tire
Number of wheels (x=drive wheels)
2x/2
Front Tire Size
5.00-8-8PR
Rear Tire Size
5.00-8-8PR
Front wheelbase
mm
925
Rear wheelbase
mm
930
Mast tilt angle (front/rear)
°
12
Mast retraction height
mm
1935
Free lift height
mm
135
Maximum lifting height
mm
3000
Maximum height during operation
mm
4335
Height of roof rack
mm
2160
Overall length (without forks)
mm
2160
Overall width
mm
1130
Fork size
mm
920*100*35
Outside fork spacing (min/max)
mm
210-1025
Mast Ground Clearance (unloaded)
mm
100
Minimum Ground Clearance
mm
85
Minimum turning radius
mm
1960
Travel speed (fully loaded/unloaded)
km/h
14/15
Lifting speed (full/no load)
mm/s
300/430
Lowering speed
mm/s
520/480
Maximum tractive effort
N
11000
Climbing speed (full/no load)
%
15/20
Traveling brake
hydraulic
Parking brake
Mechanical
Rated power of traction motor
kW
12AC
Fuel pump motor rating
kW
12AC
Battery type
Li-ion
Standard battery voltage/capacity
V/Ah
80/125
Hydraulic system working pressure
MPa
17.5
Packaging & Shipping Information
Packaging Details
Forklift Nude Packing.
Sales Unit
Single item
Rated load
2000KG
Product Highlights
★
Integrated Battery Management System (BMS)
★
Standard lithium battery
★
Standard fork
| Weight | 2000 kg |
|---|
